Printed Circuit Mounted
PRINTED CIRCUIT MOUNTED A comprehensive range of popular PRINTED CIRCUIT MOUNTED

printed circuit mounted transformers
ranging up to 130VA, usually on a double
section fully shrouded bobbin with
possible pin positions ranging from five
positions per row up to eight.

PCB With Threaded Mounting Pillars
PRINTED CIRCUIT MOUNTED As above but with four threaded corner PRINTED CIRCUIT MOUNTED

mounting pillars for added security for
the heavier transformers or where the
item may be subject to mechanical stress.
This photo shows a red flame retardant
bobbin to UL94V-0 standards.

Low Profile Printed Circuit Mounted
PRINTED CIRCUIT MOUNTED A range of popular types, or available PRINTED CIRCUIT MOUNTED

as bespoke designs to customer’s
requirements, used where height is at a
premium. Available with full approvals.

Three Phase Miniature PCB
PRINTED CIRCUIT MOUNTED A range of small three phase PCB PRINTED CIRCUIT MOUNTED

transformers available both open or
encapsulated. This particular photo
depicts a 415V/24V 10VA delta star
example with a plan area of 60 x 50mm
and a height above board of only 26mm.

9 MOST STYLES ARE INTERCHANGEABLE. CONTACT US FOR ADVICE.
