Page 35 - Louth Transformer Catalogue

LT LOW PROFILE RANGE
2.0VA TO 6.0VA 240V OR 120V INPUT
EX-STOCK 50/60Hz

A B C Wt
VA INPUT OUTPUT REF
(mm) (mm) (mm) (gms)
6V 6V 7094
9V 9V 7095
10 0/120V 12V 12V 7096
PCB 0/120V 15V 15V 7097 58 69 17 303
18V 18V
7098
20V 20V 7099
24V 24V 7100

6V 6V 7101
9V 9V 7102
18 0/120V 12V 12V 7103
PCB 0/120V 15V 15V 7104 58 69 28 390
7105
18V 18V
20V 20V 7106
24V 24V 7107

24 0/120V 9V 9V 1375
PCB 0/120V 15V 15V 1376 58 69 28 470
18V 18V
1377

6V 6V 7108
9V 9V 7109
30 0/120V 12V 12V 7110
PCB 0/120V 15V 15V 7111 58 69 31 552
18V 18V
7112
20V 20V 7113
24V 24V 7114

LOW PROFILE PRIMARY C UL94V-0 specification resin.
Tested in accordance with BS 3535
Pin
View B and EN 60742. LOW PROFILE
Fixing via four holes moulded into the
A corners of the case and the use of self
SECONDARY tapping screws.
ALL 100% RoHS COMPLIANT DATA FOR GUIDANCE ONLY. SEE PAGE 18 FOR FURTHER INFORMATION
